Zone 1/21 Polyolefin Can withstand on/off 85/85°C 230V AC ATEX, IECEx, EAC

Zone 1/21 Compact design Temperature resistant up to 200°C Quick and easy to assemble Applicable with different types of heating tapes Further sets available

Zone 1/21 Fluoropolymer Can withstand on/off 85/85°C  230V AC (Also available as 110V AC upon request) ATEX, IECEx, EAC

Zone 1/21 Fluoropolymer Can withstand on/off 100/100°C  230V AC (Also available as 110V AC upon request) ATEX, IECEx, EAC

Zone 1/21 Polyolefin 45 W/m @ 10°C, 230V AC (T3) Frost protection Can withstand on/off 100/100°C  230V AC (Also available as 110V AC upon request) ATEX, IECEx, EAC

Fluoropolymer 15, 30, 45 och 60 W/m (T3)  75 W/m (T2)  Frost protection Can withstand on/off 200/225°C  230V AC (Also available as 110V AC upon request) ATEX, IECEx, EAC

Fluoropolymer 15, 30, 45 och 60 W/m (T3)  75, 90 och 120 W/m (T2)  Can withstand on/off 200/225°C  230V AC (Also available as 110V AC upon request) ATEX, IECEx, EAC

Zone 1/21 Temperature range: from -20°C to +500°C Compact design 16A / 230V switching capacity Cross section 4 / 6mm² 4 / 6mm sensor diameter Resistant to chemical influences

Zone 1/21 Temperature resistant up to 425°C Can be cut to length without wastage Outputs available up to 150W/m Full range of controls, accessories and approvals Available for 220..277V AC 110..120V AC upon request

Approved for Zone 1/21  Dimension:  280 x 200 x 40mm Voltage: 230V Power output: 100W at 5°C Temperature class: T4 Protection class: IP 65 Temperature range: - 55°C up to +85°C

Approved for Zone 1/21  Dimension:  225 x 82 x 69mm Voltage: 230V Power output: 65W at 5°C Temperature class: T4 Protection class: IP 65 Temperature range: - 55°C up to +85°C

Approved for Zone 1/21  Dimension:  630 x 300 x 40mm Voltage: 230V Power output: 500W at 5°C Temperature class: T4 Protection class: IP 65 Temperature range: - 55°C up to +85°C

Approved for Zone 1/21  Dimension:  1030 x 420 x 40mm Voltage: 230V Power output: 1000W at 5°C Temperature class: T4 Protection class: IP 65 Temperature range: - 55°C up to +85°C

Zone 1/21 Voltage: 250V AC     Switching contact: 1 NC 16A / 250V AC Switching temperature: 4°C On / 11°C Off (other swichting points s. operation manual) Power cable: 400mm 3G1,5mm²  Cable glands: M20x1,5 Messing vernickelt

Zone 1/21 Steel flameproof construction Grey epoxy coating IP66 230V (other voltages on request) Ambient temperature range: -30°C to +40°C Check data sheet for options

Zone 1/21 Steel flameproof construction Grey epoxy coating IP66 230V (other voltages on request) Ambient temperature range: -30°C to +40°C Check data sheet for options

Protection grid ERB-PG provides extra protection against damage and touching. The grid is made of aluminium perforated plate in AISI 304, 2 mm thicknes

Heating elements: Ø8.5 to Ø12.7mm stainless steel AISI 316L or other SS grades Surface load on sheath: max. 1.3W/cm² Degree of protection: IP66 Voltage: up to 690V Design: quadrilateral, round or as an insert Temperature restrictions: all heaters are provided with a safety thermostat and thermofuse ...

Zone 1/21 For heating cables up to 150 / 200°C For 1 or 2 heating circuits No damage by sheet metal insulation No mounting plate necessary No mounting angle necessary ATEX, IECEx  II2 GD T6

Zone 1/21 Compact design Temperature resistant up to 180°C Flexible usage Different sets seperately avaible Applicable for our heating tapes

Zone 1/21 Temperature resistant up to 190°C Compact design Current rating 20A Suitable for use with many types of heating cables Version brass nickel plated Upon request Version in stainless steel

Adhesive tapes for fixing heating cables and for a better heat transfer. Aluminium Polyester Cloth adhesive tape Glass fiber tape

PT100 sensor connected to a transmitter built into a black glass fiber reinforced polyester junction box.

Zone 1/21 Compact design  Very flexible due to 3mm outer diameter  Up to 550°C  4-wire design  According to latest standards

Zone 1/21 Compact design  High resistance to chemicals  Antistatic  Resistant to corrosion/UV resistant  Individualized versions available

Marking: II2G Ex e IIC T6 ambient temp -55°C Certificates: ATEX, IECEx, EAC Dimensions: AG 99…Ex 110 x 75 x 55 AG 101…Ex 122 x 120 x 90 AG 102…Ex 160 x 160 x 90 AG 103…Ex 260 x 160 x 90

Zone 1 and 2 Ambient temperature -30°C – +50°C (-50°C … +50°C on request) The maximum permissible voltage is 690 volts Flameproof electric heater with retractable ceramic core elements. Single or multi-core heaters. For horizontal installation (vertical installation on request). The ceramic core elements can be...

Zone 1/21 Voltage type AC Frequency 50.60 Hz Designation Explosion-proof enclosure heater Heating element High-performance heating cartridge Heater body Aluminum profile, silver anodized Connection type Connection cable Connector PE 0.75 - 2.5 mm² Mounting position Air flow direction...

Zone 1/2 Voltage type AC Frequency 50.60 Hz Designation Explosion-proof enclosure heater Heating element High-performance heating cartridge Heater body Aluminum profile, silver anodized Connection type Connection cable Connector PE 0.75 - 2.5 mm² Mounting position Air flow direction...

Zone 1/21 Voltage type AC Frequency 50.60 Hz Designation Explosion-proof enclosure heater Heating element High-performance heating cartridge Heater body Aluminum profile, silver anodized Connection type Connection cable Connector PE 0.75 - 2.5 mm² Mounting position Air flow direction...

Compact versions for small enclosures with lower power output (e.g. 100–10 W) Slim models with higher power (250–25 W or 500–50 W) for tighter spaces Sturdy designs for larger compartments requiring greater heating capacity Housing options include black anodized or nickel-plated aluminum Available for T3 and T4 ...
